VETUS Swivel with Slide / PCBSR

Description VETUS Swivel with Slide / PCBSR This is a Vetus swivel with slide made with marine grade aluminium and is specifically designed for direct mounting of the seat to a box or other structure. Swivel turns through 360 degrees and the swivel has 7 locking positions through a 135mm travel. It can suit seats with a standard 7″ square mounting pattern, or a slide mounting pattern. Available in two (2) models: with operating controls on the same side with controls on opposing sides (See complete specifications on the table below.) PRODUCT TYPE HEIGHT (H) HOLE PATTERN BASE Ø WEIGHT LOAD STATIC LOAD DYNAMIC LEVER CONTROLS POSITION PCBS 70mm R/S S 2.5kg 204kg 102kg LEFT AND RIGHT SIDE PCBSR 70mm R/S S 2.5kg 204kg 102kg ONE SIDE ONLY OVERALL PRODUCT SIZE (L/W/H): 343mm x 269mm x 80mm This product is A Class and ABYC recommended as it meets the boat seat standards. NOTE – Please call us to check availability & leadtimes prior to ordering as not all Vetus items are carried in stock. Swivel 360° rotatable (R) w. 7 locking positions w slide 80x269x343
